ASPHALT & CONCRETE PRODUCT LINE

CAPACITY AVAILABLE-

10 -15 TPH

15 - 20 TPH

30 - 45 TPH

45 - 60 TPH

60 - 90 TPH

90 - 120 TPH

CAPACITY AVAILABLE-

50 TPH

60 TPH

80 TPH

100 TPH

150 TPH

200 TPH

Engine Make - Kirloskar

Battery - 12 Volts

Hopper Capacity -  (Approx.) 4 Cubic Metre

Weight(Approx) - 10 tonne

Wheel Base - 2500 mm

Operating height - 3000 mm

Paving speed - 1.25 - 23 Metres

Fuel Tank Capacity - 120 Litres

Crown - 1 to +3

Truck dumping Clearance - 600 mm

Engine Output - 76 HP at 2200 RPM

Paving Thickness 10 - 200 mm

Hydraulic Oil Tank Capacity - 80 Litres

Screed Vibration - 0 to 2000 Per Minute

Paving Width - 2.5 Metres - 4.5 Metres

Travel Speed - 1 - 16 KMPH

Length - 5560 mm

Operating Width - 3100 mm

CAPACITY AVAILABLE-

30 CBM/HR

40 CBM/HR

60 CBM/HR

70 CBM/HR

TECHNICAL SPECIFICATION

Type of Mixer – Twin Shaft Mixer

Dry Fill Capacity of Mixer Ltrs - 3000

Compacted Output per Batch Ltrs - 2000

No. of Aggregates Nos. - 4

Storage Capacity of Aggregate m3 - 70

No. of Cement / Fly Ash (Max)#No. - 5

No of Water - No - 2

No. of Additives No - 4

Aggregate Loading in Mixer–Through Belt

Connected Load#kW - 177

Aggregate Loading Height m - 6.8

Concrete discharge height m - 4.1

TECHNICAL SPECIFICATION

Parameters Unit1004 D SHP

Diesel Drive

Prime Moverk W49

Theoretical Output m - 3/hr 51 / 35* Del. Cylinder Diameter mm - 200

Del. Cylinder Stroke mm - 1000

No. of Strokes per min - 27 / 18*

Hydraulic Transmission Road Side

Head Side - 1:4.9 1:3.3

Concrete Pressure bar - 61 / 91*

Concrete Hopper Capacity L - 500

Delivery Distance**Horiz m - 400
Vert m - 100

TECHNICAL SPECIFICATION

Drum Capacity,Liter - 800

Output*Cu.M/Hr - 8

Prime Mover - 10 HP

Water Pump HP - 1

Hopper Vibrator-0.25

Guide Roller Nos - 3

Pneumatic Tyre- 600 X 16-  4 No

Loading Hopper - Hydraulic Operated Weighing System -.Electronic  Digital

Drum Dimensions mm - 1310dia X 1540 L

Mixing Drum RPM - 16

Total power HP - 12

Weight Kgs- 2400

TECHNICAL SPECIFICATION

Drum Capacity,Liter - 1050

Output*Cu.M/Hr - 10

Prime Mover - 20 HP

Water Pump HP - 1

Hopper Vibrator-0.25

Guide Roller Nos - 3

Pneumatic Tyre- 600 X 16-  4 No

Loading Hopper - Hydraulic Operated Weighing System -.Electronic  Digital

Drum Dimensions mm - 1310dia X 1540 L

Mixing Drum RPM - 20

Total power HP - 22

Weight Kgs- 3650

TECHNICAL SPECIFICATION

Automation Grade - Semi-Automatic

ENGINE - 6 HP kirloskar engines

Machine Type - Concrete Motor Power - 6 HP Motor

Packaging Type - Open Model

Output Capacity - 1000

Weight - 1000 KGS

Type Of The Drum Mixer - Tilting Drum Capacity - 1000 L

Drum Type - Round

Material - Mild Steel

Power Source - Diesel Engine

TECHNICAL SPECIFICATION

Automation Grade - Semi - Automatic

ENGINE - 8 HP kirloskar engines

Machine Type - Concrete Motor Power - 8 HP Motor

Packaging Type - Open Model

Output Capacity - 15000

Weight - 1800 KGS

Type Of The Drum Mixer - TiltingDrum Capacity - 1500 L

Drum Type - Round

Material - Mild Steel

Power Source - Diesel Engine

TECHNICAL SPECIFICATION

Automation Grade - Semi - Automatic

ENGINE - 7 HP

Machine Type - Concrete Motor Power - 7 HP Motor

Packaging Type - Open Model

Output Capacity - 500

Weight - 90 KGS

Type Of The Drum Mixer - Tilting

Drum Capacity - 260 L

Drum Type - Round

Material - Mild Steel

Power Source - Diesel Engine

TECHNICAL SPECIFICATION

Power Source - Diesel

Automation Grade - Semi-Automatic

Brand - Kirloskar

Engine - 14 HP

Output Capacity - 560 Liters

Type Of The Drum Mixer - Tilting Drum Mixer

Speed Of Mixing Drum

Other Chassis Material - Mild Steel

ChassisHeavy Duty
